FUEL  665 GAL

WATER 125 GAL

WASTE 40 GAL

FISHBOXS  74 GAL EACH

BAIT TANK 85 GAL

DISPLACEMENT  43,500

L.O.A.   42’ 6”

B.O.A.   15’ 6″

DRAFT 4’

CONFIGURATIONS : SPORTFISH + EXPRESS HARDTOP

DEADRISE AT TRANSOM 18°

100% Vinylester Resin Construction.

Gurit A500 Cored Hull Sides With A Solid Glass Bottom

Propeller Pockets To Reduce Draft

Angled Transom Below Waterline To Enhance Maneuverability In Reverse

Exhaust Exits In Corners Of Boat For Enhanced Performance

Oversized Fiberglass Encapsulated Full Length Stringer System

Molded 665 Gallon Fiberglass Fuel Tank With Fiberglass Baffles Integrated Into The Hull

Modified Rudder Shelf Design To Optimize Space In Aft Lazarette

Integrated Bilge Pump Shelfs Allow Smooth Operation Of All Bilge Pumps.

Epoxy Barrier Coat On Hull Below The Waterline

Integrated Bow Thruster Tunnel With Fairing Built Into The Hull For Unmatched Strength

Dedicated Transducer Pocket Integrated Into The Hull.

Molded Diamond Nonskid Throughout Boat.
1 Stateroom 1 Head Arrangement

Vacuum Bagged Cored Composite Bulkheads

Oversized Sea Strainers In Aft Lazarette For Washdown And Bait Pumps

Seastar Eps Electric Hydraulic Steering System Standard.

Independent Hydraulic Steering Rams Positioned Outboard For Increased Lazarette Access

Oversized Bilge Pumps Connected To Switches For Automatic And Manual Operation

Dockside And Overboard Pumpouts For Holding Tank

Fire Suppression System Automatically Or Manually Operated And Tied Into Main Engine And Generator Ignition Systems With Override

24v Fuel Priming Pumps For Main Engines

Oversized Sea Strainers For Main Engines And Generator

"Crash Valve" Off Engine Intakes For Use As Emergency Bilge Pumps

In-line Mufflers On Vibration And Sound Dampening Mounts With Surge Tube In Engine Room.

Oil Change System Pump For Main Engines, Transmissions, And Generator With Pump Out Line

Pex Plumbing For All Freshwater Hot And Cold-Water Lines

Pressurized 24v Freshwater System With Deck Fill And Supply Inlet.

Racor Fuel/Water Separators For Main Engines And Generator

Rudders, Stainless Steel, With Composite Rudder Bearing And Drip-less Seal Laminated Into Hull

Seacocks, Bronze, Ball-type Sea Valves And Strainers For All Thru- Hulls Below The Water Line

2 Aquamet High-strength Stainless Steel Shafts, Double-taper With Machined Keyway And Thrust Plate At Main Engine Coupling

Nibral Thru Water Struts Optimized For High Performances

Zipwake Interceptor Trim Tabs With Internal GPS And Individual Controls At Helm

Seakeeper Sk6 Gyro Stabilizer Mounted Centerline Between Stringers

Onan 13.5 Kw E-qd Electronic Quiet Diesel Generator With Housing

12 Gallon Hot Water Heater For Freshwater System

24v Dc Throughout

12v And 24 Power Supply With Breakers For Future Electronics And Systems

Battery Banks In Fully Accessible Fiberglass Box

Battery Charger With Thermal Cutoff And Integrated Switching System

Battery Distribution Panel With Cutoff And Breakers Mounted In Engine Room

Battery Parallel System For Main Engines And Generator Start

Color Coded, Numbered And Labeled Wiring Throughout With Accompanying Diagrams

Glendinning Cable Reel With 75' Cord And Additional 220v Inlet In Cockpit

Master Electrical Control Panel Located In Salon With 24v/110v Circuit Breakers, Individual Switching For Power, Or Generator Supply And Gauges For Electrical Supply, Voltmeter And Ampmeter

Bonded Electrical System With Ground Plate

All Tinned Copper Wiring With Marine Rated Insulated Jacket.

All Connectors Are Heat Shrunk And Thermally Labeled

Dual Air Horn

Full Dc Engine Room Led Lighting

Fresh And Saltwater Washdown Spigots

Glendinning Hose Reels With 20' Hose For Fresh And Saltwater Washdowns In Cockpit

Oversized Lazarette Hatch With Ample Access To Aft Bilge And Rudder Shelf

Full Round Rubber Gasket On All Lids And Access Doors

Laminated Oversized Garolite Plate In Cockpit For Future Fighting Chair Or Pedestal

Flush Mounted And Screwless Gemlux Rod Holders (4) In Coaming.

316 Stainless Gas Pistons On All Lids

Two Thin Mounted Stereo Speakers Under Gunnel

Two Oversized 73.5 Gallon Insulated In Deck Fishboxes With Independent Macerator Pumps

Oversized Integrated Transom Livewell With Integrated Window, Livewell Lights And Non-Intrusive Fill And Drain Fittings

12" Stainless Steel Cleats In Corners With Custom 316 Oversized Hawse Pipes

Oversized Direct Overboard Cockpit Drains With Stainless Steel Covers

Diamond Nonskid On Cockpit Floor And Gunnels

Rounded Molded Gunnels For Added Aesthetics And Comfort

Generous Sized Transom Opening Door With Folding Gate And Oversized Custom Stainless-Steel Hinges And Hardware

Indirect Color Changing Strip Lighting Under Gunnels

Controls: Tournament Lever Controls Mounted On Fiberglass Helm Pod

Electronic Trolling Valves

Electric Hydraulic Fully Adjustable Steering

Fire System With Automatic And Manual Discharge With Control On Console

Engine Manufacturer Supplied Gauges And Electronics

Helm Console Mounted On Actuator For Full Access To Necessary Systems

Triple Helm Seat Configuration With Fully Adjustable And Rotating Seats.

Lighted Flush Mounted Compass On Console

L-shaped Lounge Seating With Premium Upholstery

Manual Engine Start/ Stop Switches In Console Box

4x Fast Charge USB Charging Outlets Located In Console Electronics Box

Recessed Stereo Speakers

Molded Fiberglass Diamond Nonskid Deck

Mezzanine Seating With Insulated Drink Lockers

Oversized Insulated Freezer Locker

Integrated Gaff Locker Able To Accommodate 8' Gaffs

Oversized Fishing Tackle Station To Starboard

Hydraulic Powered Actuating Helm Deck For Easy Access To Engine Room And Components

Oversized Access Hatch In Deck For Engine Room Access

Premium "Glass Dash" Mounting System For Electronics

Sound Insulated Helm Deck Floor For Reduced Engine Noise.

Release Marine "Carolina Classic" Helm Chairs

Molded Fiberglass Windshield Frame With Integrated Track For Future Curtains

Safety Glass Windshield And Side Windows In Hull

Premium Speakers (4) And One Recessed 10" Subwoofer With Amplifier

Dual Zone Air Conditioning With Reverse Cycle Heat And Control

Teak And Holly Floor

Dinette "L-shaped" Lounge With Storage Underneath

Dinette Table With High Gloss Wood Finish

Electric Range Surface Mounted In Galley

High Gloss Corian Counter Top In Galley

Overhead Led Lighting Throughout

Accent Led Lighting Under Galley Toe Kick And Behind Valences

Main Electrical Panel Mounted Centerline Aft, Ac/Dc And Backlit For Easy Access

Microwave/ Convection Oven Located In Upper Galley Cabinet

Oversized Galley Sink With Stainless Steel Faucet

Sliding Drawer Refrigerator And Freezer In Galley

Sliding Salon Door

Deep Storage Under Salon Steps

Dedicated Electronics Storage Complete With USB Plugs And Connectors For Tv

Bulkhead Mounted 42" Flat Screen Tv With Premium Sound

Stowage Cabinets In Galley And To Port

Flip Up Dinette Backrests Serve As Additional Berths

Large Access Hatch To Midship Bilge

Large Skylights In Main Salon

6' Hull Side Window To Port With Tinted Safety Glass

Air Conditioning Vent

Electric Head With Overboard And Holding Tank Discharge

Fiberglass Nonskid Flooring

Lower Vanity With Storage

Corian Countertop With Fiberglass Sink And Stainless Faucet

110v Receptacle With Gfci

LED Shower Light

Fiberglass Shower Stall With Handheld Nozzle And Mount

Tinted Safety Glass Hullside Window

Towel Ring

Air Conditioning With Reverse Cycle Heat And Controller

Island Double Bed With Mattress And Lift Up Base With Generous Storage Underneath

Drawer Storage Under Bed With Three Drawers And One Cabinet

Steps On Each Side Of Island Bed

Access Hatch For Bow Thruster

Two Large Cedar Lined Closets Outboard

Overhead Led Lighting

Rod Storage Lockers On Upper Outboard Sides Of Stateroom Able To Accommodate 7.5' Rods

Teak Shelf

Optional 30" Flat Screen Tv Mounted On Wall

110v Receptacle With Gfci

Foredeck Hatch With Screen

Anchor Locker With Access From Foredeck.

Oversized Windlass With Custom Anchor Roller Assembly And Ultra Anchor

Anchor Rode, 300' Rope And 50' Chain

LP Bilges And Access Areas For Easy Cleanup

316 Stainless Steel Grab Rails Throughout

Foredeck Hatch With Screen

Painted Rub Rail

Stainless Steel Hardware Throughout Boat

Stainless Steel Bow, Spring And Stern Cleats

Mooring Lines

Safety And Commissioning Kit

Fire Extinguishers (5)
